Name: PCB Prototype &amp; Turnkey PCB Assembly Manufacturing
SKU: 34179
Price: 1.00 USD
Availability: InStock
Rating: 5.00 (39 reviews)

PCB Specification Selection

+ Add Gerber File

Automatically sets board size. Accept .zip / .rar / .7z (Max 50MB) Preview is for reference only — you can always order; final check by our engineers.

Base Material ? FR-4 is the most popular substrate material for rigid PCBs.
Flex PCBs utilize a thin, flexible polymer film as the substrate for the circuitry. Flex PCBs reduce space consumption, and have lower weight.
Aluminum/copper core boards have better heat dissipation and thermal transfer than standard FR-4 constructions.
Note: For Aluminum/Copper core boards, the min drill size is 1.0mm, and min slot width is 1.6mm.
Rogers/Teflon PCBs have excellent dielectric properties and minimal resistance. They are generally used in high-speed, high-frequency circuitry applications.

Layers ? Number of copper layers.
Odd layer counts will be fabricated as the next even layer.

High Precision PCB

Layers ? Flexible PCBs commonly use 1, 2 or 4 layers.

Layers ? Aluminum PCBs are typically 1 or 2 layers.

Layers ? Copper core boards are typically 1 or 2 layers.

Layers ? Rogers high-frequency boards are commonly 2 layers.

Layers ? PTFE boards are commonly 2 layers.

Dimensions ? Board length and width.
You can switch between mm and inch.
Calculation always uses mm internally.

PCB Qty ? Number of boards you need. Higher quantity usually gets better unit price.

pcs

Different Design ? Number of different designs in one Gerber file.

Delivery Format ? Single pieces or panelized boards.

PCB Thickness ? Standard is 1.6mm. Thinner for compact devices, thicker for better strength.

PCB Color ? Soldermask color of the board.

Silkscreen ? Color of the component legend print.

Surface Finish ? HASL: Low cost, good solderability.
ENIG: Flat surface, better for fine-pitch.
OSP: Organic coating, environmentally friendly.

Outer Copper Weight ? Copper thickness on outer layers. 1oz is standard.

Via Covering ? Tented: Covered by soldermask (most common).
Untented: Vias left open.
Plugged: Filled with resin.

Castellated Hole ? Plated half-holes on the board edge.
Minimum diameter usually 0.60mm.

Gold Fingers ? Edge connector plating. Select Yes if your design has gold fingers.

Impedance Control ?Yes = +¥100 per design.

Electrical Test ? Flying probe test to check for opens and shorts.

Substrate Type ? Dielectric thickness of the flexible material.

PCB Thickness ? Typical thickness options for flexible PCBs.

Coverlay Color ? Color of the coverlay film on flexible boards.

Silkscreen ? Legend print color on flexible boards.

Copper Type ? Electro-deposited: Common, lower cost.
Rolled Annealed: Better flex life.

Surface Finish ? ENIG is the most common surface finish for flexible PCBs.

Gold Thickness ? Gold thickness for ENIG finish.

Outer Copper Weight ? Copper thickness. 1/3 oz and 0.5 oz are common for flex.

Stiffener ? Rigid material added to support connectors or components on flex boards.

EMI Shielding Film ? Electromagnetic shielding film for flexible circuits.

Cutting Method ? Laser cutting is more precise for flexible boards.

PCB Thickness ? Common thicknesses for aluminum substrate boards.

Thermal Conductivity ? Higher value means better heat dissipation.

Breakdown Voltage ? Insulation strength of the dielectric layer.

PCB Color ? Soldermask color for aluminum boards.

Surface Finish ? HASL and OSP are common for aluminum PCBs.

Outer Copper Weight ? Copper thickness on the circuit layer.

PCB Thickness ? Common thicknesses for copper core boards.

Copper Structure ? Direct heatsink structure for maximum thermal performance.

Thermal Conductivity ? Copper core offers very high thermal conductivity.

Surface Finish ? OSP is commonly used for copper core boards.

Outer Copper Weight ? Copper thickness of the circuit layer.

Material Type ? Select the specific Rogers laminate model.

PCB Thickness ? Available core thicknesses for Rogers material.

PCB Color ? Soldermask color.

Surface Finish ? ENIG is recommended for high-frequency boards.

Gold Thickness ? Gold thickness when ENIG is selected.

Via Covering ? How vias are treated.

Material Type ? Select the specific PTFE laminate model.

PCB Thickness ? Available thicknesses for PTFE material.

PCB Color ? Soldermask color.

Surface Finish ? ENIG is recommended for PTFE high-frequency boards.

Gold Thickness ? Gold thickness when ENIG is selected.

Outer Copper Weight ? Copper thickness on outer layers.

Via Covering ? How vias are treated.

PCB Remark

Shipping Country

Shipping Cost

SMD-Stencil (Order together with PCB)

Framework ? No (Non-framework): Foil only, lower cost.
Yes (Framework): With aluminum frame, easier for repeated printing.

Step Stencil ? Step stencils provide different solder paste volume for components that need different paste amounts on one PCB.
Currently two thickness levels are supported. If Yes, describe step regions in Remark.

Stencil Side ? Top only: 1 stencil, top side Gerber.
Bottom only: 1 stencil, bottom side Gerber.
Top+Bottom (Single): 1 stencil, both sides on one foil (size ≥ 2× PCB).
Top+Bottom (Separate): 2 stencils, price ×2.

Please select the Stencil Side according to your design requirements.

Dimensions ? Overall stencil size and valid working area.
Choose a size larger than your PCB.

Stencil Qty ? Number of stencils required.
Top + Bottom (Separate) forces quantity = 2. pcs

Thickness ? Choose thickness by component pad size.
Common default: 0.12–0.15mm.
Engineers can also select based on your files if needed.

Process Type ? Solder paste stencil: Most common for SMT.
Red glue stencil: For adhesive dispensing.

Polishing Process ? Sanding: Standard, general use.
Etching: Economical deburring.
Electropolishing: Smoothest surface, better paste release. Recommended for ≤0.5mm pitch IC / BGA. (+$12)

Fiducials ? Alignment marks for SMT machines.
Hand assembly usually does not need fiducials.
If required, select Etched Through / Half and include them in the design file.

Engrave Text ? Laser engrave text on the stencil (e.g. order #, file name).
If Yes but no text in Remark, file name and order # will be used.

Stencil Remark ? Step regions, 1:1 aperture request, PO number, engrave text, etc.

Notes:

① Stencil aperture openings follow factory standard by default. For 1:1 opening, leave a remark.

② Provide clear Gerber paste layers to reduce engineering questions.

PCB Assembly

Assembly Type

Board type

Assembly side(s)

Quantity pcs

Sensitive components

Accept alternatives

Required Files for Assembly

Parts List (BOM) Upload

Centroid File Upload

Other Assembly Files

+ Other Parameters Fill in to get the exact price, or leave blank for final quote.

More ▾

+ Customized Services and Advanced Options Below options are not included in online quotation

More ▾

Detailed information

Assembly requires manual quotation. Gerber file is already uploaded above.

We will reply within 1 business day.

Pricing & Build Time

PCB Cost $0.00

Base MaterialFR-4

Layer2 layers

Dimensions100×100 mm

PCB Qty5

Different Design1

Delivery FormatSingle PCB

PCB Thickness1.6 mm

PCB ColorGreen

SilkscreenWhite

Surface FinishHASL

Copper Weight1 oz

Via CoveringTented

Castellated HoleNo

Gold FingersNo

Impedance ControlNo

PCB Stencil Cost $0.00

Stencil typeNon-framework

Size—

Stencil SideTop Only

Quantity1

Thickness0.15 mm

ProcessSolder paste

PolishingSanding

FiducialsNo Fiducial

Engrave TextNo

PCB Assembly Service Quote

ServicePCB + Assembly (manual quote)

Engineering Fee$0.00

Special Process$0.00

Sub total$0.00

Est. Weight0 g

Final price subject to review after file check.
Shipping calculated at checkout.
