Key features
- Equipped with ESP32-S3R8 Xtensa 32-bit LX7 dual-core processor, up to 240 M H z main frequency
- Supports 2.4 G H z W–i-F–i (802.11 b/g/n) and BLE 5 (LE), with onboard antenna
- Built in 512KB of SRAM and 384KB ROM, with onboard 8MB PSRAM and an external 16MB Flash memory
- Type-C connector, keeps it up to date, easier to use
- Onboard 1.69inch 240×280 pixels 262K capacitive touch display for clear color pictures
- Built-in ST7789V2 display driver and CST816T capacitive touch chip, using SPI and I2C communication respectively, effectively saving the IO resources
- Onboard QMI8658 6-axis IMU (3-axis accelerometer and 3-axis gyroscope) for detecting motion gesture, counting steps, etc.
- Onboard RST, BOOT and a programmable PWM button for easy custom function development
- Reserved pads of 4 × GPIO, I2C, and UART interface, for connecting peripherals and debugging
- High touch screen transmittance, fast response and long lifetime
- Comes with Online Tutorial Usage Guide and Online Development Resource, Please check: n9.cl/5138t
- Package Content: ESP32-S3-Touch-LCD-1.69 x1
